Customized Glass Melting Furnace with PLC Control System for Clear Container Glass Production

Name: Customized Glass Melting Furnace with PLC Control System for Clear Container Glass Production
Brand: JEFFER Engineering and Technology Co.,Ltd
SKU: Disesuaikan
Availability: InStock

Nama Merek:	JEFFER
Nomor Model:	Disesuaikan
Moq:	1 set
harga:	dapat dinegosiasikan
Waktu pengiriman:	160 hari setelah menerima uang muka
Ketentuan Pembayaran:	T/T,L/C

Informasi Detail

Deskripsi produk

Informasi Detail

Tempat asal:

Chongqing

Sertifikasi:

ISO9001, ISO14001, ISO45001

warna kaca:

Jernih

Bahan:

Bahan refraktori, struktur baja

Jenis kaca:

Soda-kapur

Waranty:

Setahun

Produk:

Kaca wadah

Kondisi:

BARU

Konsumsi:

Penghematan energi

Kapasitas:

Disesuaikan

Sistem Pengendalian:

PLC

Layanan purna jual:

Layanan Rekayasa Luar Negeri Tersedia

Kemasan rincian:

Kotak kayu, baki, bingkai baja, dll

Menyediakan kemampuan:

1 set per 4 bulan

Menyoroti:

One Year Warranty Glass Melting Furnace

Clear Container Glass Melting Furnace

PLC Control System Glass Tank Furnace

Deskripsi produk

Customized Glass Melting Furnace with PLC Control System for Clear Container Glass Production

Brief Introduction

Glass melting furnace refers to the thermal equipment used in glass manufacturing to melt glass mixtures. Mix the powder prepared according to the glass composition and the added clinker (broken glass) at high temperature in the kiln to melt, clarify, and form a glass liquid that meets the forming requirements.

Glass manufacturing has a history of 5000 years, and the manufacturing method of using firewood as fuel and melting glass materials in clay jars has continued for a long time. In 1867, the Siemens brothers in Germany built a continuous coal-fired tank furnace. After 1945, glass melting furnaces developed rapidly.

Melting Process Stages

Silicate forming: The mixture is converted into a sintered material composed of silicates and silica.
Glass liquid forming: The sinter will be melting and the silicate and SiO2 in sinter will change to flint glass liquid with a plenty of bubbles.
Clearing: The glass liquid is continuously heated, and its viscosity is reduced with plenty of gaseous sundries released, which should eliminate the visible bubbles with the pool of liquid.
Homogenization: The glass liquid is kept at high temperature for a long time, the ripple eliminates by diffused function and homogenizes as a whole.
Cooling: Adjust the viscosity to be suitable for forming.

Furnace Melting Technology System

Furnace melting technology includes temperature, pressure, bubbling, glass liquid level, fuel, reversing system etc.

Item	Description
Temperature	The temperature means the temperature of the melting tank, not the whole furnace. The distribution of temperature is from the melting tank through the length of the furnace.
Pressure	Furnace pressure is the static pressure of the gas system, which is determinate by pressure distribution curve.
Bubbing	Stable shape and position of bubble are an important sign to estimate the melting performance, which will also affect the production capacity of furnace and quality of glass liquid.

FAQ

Q: Who we are?

A: JEFFER Engineering and Technology Co., Ltd is a professional engineering company specialising in project design, engineering technology consulting, engineering, procurement, construction (EPC), and project operation management.

Q: Can you offer design service?

A: Yes, we could design full solution drawings as per your requirements.

Q: Do you offer installation on site overseas?

A: Yes, we can provide our engineer to supervise the installation work on site or provide the whole installation team on site to finish the project.
